wool felt cutting machine

Gerson wool felt cutting machine can die cutting most wool felt material and production for :Industry Wool Felt,Polishing Felt Wheels,Buffing pad &Polishing Bonnet,Wool Felt Bobs,Oil Seals & Felt Seals Pads,Felt Strips & Felt Canister,Felt Wicking,Stickiness Felt,Felt Sheet,Protector Felt Pads,Wool Felt Insoles etc.,

Most Gerson customers like to use Gerson traveling head press to die cutting their felt. So traveling head press is very popular in wool felt plant or factory.

The traveling head press is one of die cutting machine with traveling head .A travelling head die cutting press can process material in roll form as well as sheets, in their full width, without previously ranging down. Larger head sizes and cutting forces will allow cutting of a wider range of materials, in single or multiple layers, with larger cutting dies, although small dies can be used equally as well.

wool felt cutting machine
wool felt cutting machine

There have two kind of traveling head press :manual traveling head press and CNC traveling head press.

The following is CNC automatic traveling head cutting press advantage and features:

a. Digital control system of “PLC + coder” human-machine interface is adopted to realize automatic feeding, pattern arrangement and cutting. Five kinds of arrangement figures are optional for automatically setting cutting times with high precision. The positioning precision can reach 0.2mm so as to save materials, enhance work efficiency and reduce labor intensity.
b. PLC program control center is provided with memory function for the settings of operation instructions, which are not influenced in case of power failure or power-cut after work, so as to facilitate operation for the next time.
c. Double oil cylinders drive, four-column guiding and automatic balancing are adopted to guarantee identical cutting depth for each time.
d. Three operation modes such as automatic, semiautomatic and manual operations are optional, which are free and flexible.
e. The cutting head can carry out automatic transverse movement and automatic positioning. The die cutter is fixed by electromagnetic suction disc. Without the need of setting die cutters, the upper and lower die cutters can carry out cutting freely with convenient operation.
f. The automatic lubricating system ensures machine precision and prolongs service life.

Model GRM(A)-25T to 200T
Max cutting force(T) From 25 Tons to 200 Tons
Range between working table 50-240mm (Upper to Bottom Table)
Stroke Adjustment 0-170mm
Cutting table width(mm) 1800~2500mm or more
Based on your material and die
Example: 1600X600mm etc.,
Cutting Head

Movable trolley

500×500 to 1000x1000mm
Motor power 3kw to 22KW
Electric Power 220V/380V/415V,50-60hz etc.,
Machine Net weight (KG) 1600 to 16500
1700 to 17500

Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
