Three keys swing arm hydraulic clicker press

Three keys swing arm hydraulic clicker press is one kinds of Gerson clicker press designed for cutting soft and semirigid material with one laer or mutilayers.

Three keys swing arm hydraulic clicker press
Three keys swing arm hydraulic clicker press

1.This hydraulic clicker press can be cutting the material such as :compound,leather,fabric,plastic,Nylon,cardboard,paper,cork,rubber ,and other synthetic materials.

2.The three keys are set for different cutting die/knife,So the operator donot need any change when change another cutting die/tool.That means:these three push buttons act as power selectors and the
operator has not to adjust the power each time he changes the cutting- die size.

3.Robust strong struchture ,top quality hydraulic parts and central autoamtic lubricating system ensure s machine precision and prolong service life.

4.Two hands operation make sure high safety and very low noise even can use in lab.

5.The below is details specification for this model.Gerson also have any other model machine,please contact if you have any qeustion ,Gerson can custom build any machine for your production.





Model Cutting Table UP Beam Head Max Pressure Net Weight
GRA/3-270L 1000×500 610mm 25T–245Kn 1050 (kg)
GRA/3-270M 1000×500 500mm 25T–245Kn 1030 (kg)
GRA/3-270C 900×450 500mm 25T–245Kn 900 (kg)
GRA/3-250L 1000×500 370mm 25T–245Kn 990 (kg)
GRA/3-250M 900×450 370mm 25T–245Kn 880 (kg)
GRA/3-220L 1200×500 500mm 22T – 216Kn 1060 (kg)
GRA/3-220M 900×450 370mm 22T – 216Kn 880 (kg)
GRA/3-220C 900×430 370mm 22T – 216Kn 630 (kg)

Electric Supply Voltage:  3 phases×440/415/400/380/220/200V, 50/60 Hz,

Single phase:110V/240V/220V, 50/60 Hz
