Synthetic leather/fabric sheet football die cutting machine

Gerson die cutting machine is designed for die cutting synthetic leather/fabric sheet for making footbal soccer ball, Basketball, Handball,Volleyball, Rugby Balls,American Football or any other sport ball.

 Synthetic leather/fabric sheet football die cutting machine

Synthetic leather/fabric sheet football die cutting machine



1.all Synthetic leather sheet or simliar material can be die cut into hexagonal and pentagonal shapes by the cutting die/knife.
2.Hydraulic driven make the high speed with moving head cutting ,The moving head can move easily by operator hand or control by PLC (automatic feeding and die cutting ).
3.Strong construction amd automatic lubricating system ensures machine precision and prolongs service life.
4.This move head cutting machine is also suitable for cutting single layer or multiple layers of soft and nonmetal materials.
5.The move head size and cutting force for choice or can custom built.

Model GRM(A)-25T to 200T
Max cutting force(T) From 25 Tons to 200 Tons
Range between working table 50-240mm (Upper to Bottom Table)
Stroke Adjustment 0-170mm
Cutting table width(mm) 1800~2500mm or more
Based on your material and die
Example: 1600X600mm etc.,
Cutting Head

Movable trolley

500×500 to 1000x1000mm
Motor power 3kw to 22KW
Electric Power 220V/380V/415V,50-60hz etc.,
Machine Net weight (KG) 1600 to 16500
1700 to 17500

Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
