Die Cutting Machine
38 Years+ Manufacturer
Quote Now

Swing beam cutting machine 10/12/14/16/20/25/27 tons

Gerson Swing beam cutting machine is for die cutting of soft and semi-rigid materials in sheet form .Such as gaskets,paper, foam & rubber, packaging, abrasives, plastics, auto interior components, composites, industrial textiles, shoes footwear & leather,auto parts,electronics etc.,

Swing beam cutting machine 10/12/14/16/20/25/27 tons
Swing beam cutting machine 10/12/14/16/20/25/27 tons

Swing beam cutting machines is  also known as clicking presses or clicker presses.

1. safe and simple to operate with the operator having only to place the material on the bed of the press, position the cutting tool on the material and press the twin, operating buttons.
2.The swing beam descends under hydraulic power to cut the required cut shape from single or multiple layers of sheet material.
3.Easy to operate with swing arm and button press.
4.Economic cost and stable working function.
5.This swing arm cutting machine table size is about 900mm*400mm,900mm*430mm,1000mm*500mm etc.,The cutting force is from 8 Ton ,10 Tons, 12 tons,14 Tons,18 tons,20 Tons,22 Tons, 27/28 Tons etc.,

Model GSB,GR,GRA,GRB serials
Maximum   Cutting Force 8Tons-500Tons or More
Cutting speed 0.085m/s
Adjustable stroke 5-300mm or more
Tension distance 60-350mm or more
Cuttting table size 650×330 to 3000×2500mm
size 660×780×1500 to 2800×3200×1700mm
Motor Power 0.75kw to 22Kw
Net Weight (N.W.) 550 to 18000kgs
