Steel rule die clicker press is one cutting machine for steel rule die which can die cut out the material from required size.
1.It is widely used to many industry :such as shoes,package,bags,auto,gasket etc.,It is cutting our from the material :leather ,fabric,paper,foam,plastic ,rubber etc,
2.It is cutting with steel rule die ,and it is also can work with forged die or other similar dies.
3.It is great for die cutting, flattening, pressing etc.Good for used for home business and small industry.
4. It is easy operation and very safe for operater.Quick and low maintenance.
5.Any more information ,please contact Gerson.
| Model | GSB-2C/10/12/14/15/16/18/20/25 |
| Cutting Force | 10,12,14,15,16,18,20,25 Tons |
| Sway Arm Width | 330X450mm,350X450mm,450X550mm |
| Stroke Adjustment | 5-75mm |
| Distance Between Upper Table And Lower Table | 60-140mm |
| Table Area | 900X400mm,1000X500mm |
| Electric Supply Voltage | 3×440/415/400/380 /220V, 50/60 Hz |
| Motor Power | 0.75kw,1.1kw,1.5Kw |
| Packing Size(LXWXH) | 1100X1100X1700mm |
| Weight | 500Kg/650kg/1000kg/1100kg |
| Hydraulic oil (46#) | 50 Liters |
