Small hydraulic punch press machine

Small hydraulic punch press machine is the die punch press machine for cutting out small parts from the most soft and semi-rigid material:leather,rubber,paper,fabric ,cork,plastic etc.,It is good used in small plant or shop or home .Also it is used as a sample die punch press machine.

Small hydraulic punch press machine
Small hydraulic punch press machine

1.The small type punch press machine have 8T /tons cutting pressure.

2.Double hand required operation which make sure the high safety for the operator.

3.Work with the samll cutting die/tool/knife ,so that can die punch out any shapes.

4..The upper press head or arm can move horizontal easily . just put the material on the bed and place the die on the material .Press the button with both hands,the press head will punch down the material.After punch ,the head will rise up to its original position.

5.Any more information or question ,Contact Gerson any time.

Model: GSB,GR,GRA
Cutting Force: 10 Ton (from 8 ton to 20 tons)
Bed Size: 330,400,500 x 1000,800,900,1200 mm
Cutting Stroke: 0-75 mm
Distance between beam to Bed: 65-150 mm
Motor Power:0.75kw, 1.1KW,1.5 KW
Hydraulic Oil: 60 Liter of 46 anti-wear hydraulic oil
Net Weight: 400-1000 KGS
Dimension: small size to 1100 x 1100 x 1400 mm
