Gerson small hydraulic clicking press is mini die cutting press with hydraulic driven .This small hydraulic clicking press is used for die cutting most small leather,paper,fabric,plastic ,rubber material in shop,home,lab and small factory plant.
Small Hydraulic Clicking Press
1. Operation by two hands and no continuous cutting make the machine highly safe.
2. The cutting stroke can be adjusted speedily in accordance with the height of cutter and the thickness of material.
3.It applies to the shaping and the cutting of one layer or several layers of the materials such as, leather, rubber, canvas, nylon, cardborad, and so on
4.More large cutting force and cutting table can custom build for large die cutting requirement.
| Model Number | GSB-8/10 |
| Cutting area | 650*350mm |
| Arm width | 370*275mm |
| M.C.F. | 8-10tons |
| Power | 2HP |
| Stroke | 5-95mm |
| G.W. | 550kg |
| N.W. | 500kg |
| Color | custom built |
| Dimensions | 650*750*1500mm |
| Packing size | 800*850*1700mm |
| Voltage | three/single phase,380v/220v |
| Hydraulic oil | 46# 48# 68# |
| Function | Die cutting |
| Automatic Grade | Semi-Automatic |
| Machine | Hydraulic cutting machine |
| Driven Type | Hydraulic |
| Type | cutting machine |
| Condition | New |
