The die cutting machine cutting sheep leather,goat leather which for different usage: wallet, shoes, clothing ,bag etc.,
The following is for big size sheep leather.If you cutting small piece, the swing arm cutting machine can be good choice from 8ton to 28 tons.
This cutting machine can be also for plastic,rubber,paper,cock etc.,soft and semi-rigid materials.
Feature:
1.Heavy-duty four-column guiding,double-crank balancing which make sure the speed and accuracy of die cutting.
2.Very efficient for cutting multiple layers of material
3.Automatic lubricating system guarantees machine precision and prolongs life of machine ,low maintenance.
4.Low noise and very quiet,high speed
5.single feeding or double feeding system,PLC controlled, available for your choice.
6.Can manufacturing the customer detailed requirement.
7.Special requirement can be custom made.
| Model | GSB,GR,GRA,GRB serials |
| Max cutting force(T) | 8Tons-500Tons or More |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting table | 650×330mm to 3000mm×2500mm |
| Based on your material and die | |
| Example: 1000X500mm etc., | |
| Cutting Head | 330×450 to More |
| Motor power | 0.75kw to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
