Gerson die cutting machine for sandpaper,sandpaper sheet,sandpaper disc,sandpaper grit,Abrasive Belts,Abrasive Paper etc.,
The most sandpaper making factory like Gerson travelling head cutting machine.This die cutting machine are widely used for cutting sandpaper products.
For high volume production,Gerson CNC traveling head press will be good choice,also CNC traveling head press can be die cutting for most soft and semi-rigid material.
The cutting jobs and patterns are pre-programmed into the cutting press machine computer or this can be carried out off-line and information sent down to the machine. Thus, the operator has no more to do than load the material and cutting tool and gather the cut pieces as they emerge from the machine: the machine dictates the speed, accuracy and material yield.
1.Both for cutting soft or semi-rigid in single layer or multiple layers.
2.Cutting head left and right together with the cutting dies ensures the clear view over the table.
3.Fully automatic cutting system avaliable including feeding, cutting, knock-out and stacking system make high productive.
5.Large cutting bed with 500*500mm trolley or 600*600trolley or more wide trolley ,Any size trolley can custom made.
6.From 25T to 100Tcutting force for choice or can custom made.
7.Special custom design or specifications welcome.
| Model | GRM(A)-25T to 200T |
| Max cutting force(T) | From 25 Tons to 200 Tons |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting table width(mm) | 1800~2500mm or more |
| Based on your material and die | |
| Example: 1600X600mm etc., | |
| Cutting Head
Movable trolley |
500×500 to 1000x1000mm |
| Motor power | 3kw to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
