Die cutting machine for rubber o-ring such as : NBR, CR, NR, SBR, EPDM, FKM, SILICON etc.,
From the smallest 25 Ton for the largest 500 Tons and up on request, Gerson Precise cutting machine are adaptable to some lots of applications. Suited to cutting many materials, including:
Carpet,Felt,Card,Paper,Flooring,Foam/Sponge,Shoe Materials,Craft Products,Cork,Plastic,Leather,Rubber,gasket materials,Electronics,Textiles;and others more material.
Model | GRB(C)-25T to 500T |
Max cutting force(T) | From 25 Tons to 500 Tons |
Range between working table | 50-240mm (Upper to Bottom Table) |
Stroke Adjustment | 0-170mm |
Cutting area(mm) | (500-3000)X(500-3000)mm |
Based on your material and die | |
Example: 1600X700mm etc., | |
Motor power | 1.5 to 22KW |
Electric Power | 220V/380V/415V,50-60hz etc., |
Machine Net weight (KG) | 1600 to 16500 |
1700 to 17500 |
Because these versatile die-cutting presses take only seconds to setup, they are ideal for small-medium quantity orders for small-medium size parts, as well as sample and prototype orders for products under development. The machines are capable of producing up to 300 strokes per hour, making them the most cost-effective press on runs under 1,000 pieces that would otherwise require relatively lengthy setups.
Model | GSB,GR,GRA,GRB serials |
Max cutting force(T) | 8Tons-500Tons or More |
Range between working table | 50-240mm (Upper to Bottom Table) |
Stroke Adjustment | 0-170mm |
Cutting table | 650×330mm to 3000mm×2500mm |
Based on your material and die | |
Example: 1000X500mm etc., | |
Cutting Head | 330×450 to More |
Motor power | 0.75kw to 22KW |
Electric Power | 220V/380V/415V,50-60hz etc., |
Machine Net weight (KG) | 1600 to 16500 |
1700 to 17500 |
Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
