Gerson Non Woven Felt cutting machine is the machine for die cutting Non Woven Felt:Cured Felt(acoustic material for roof panel insulation, floor carpet underlay, bonnet, boot insulation ),Fire Resistant Felt(heat and sound insulator for automotive industry)
We know Non Woven Felt is non-woven textile that is produced by matting, condensing and pressing fibres together.
There have some models for die cut felt .The following is beam press for cutting non woven felt .
1.The machine can also for any other non-metal material:Cloth,Coated Fabrics,Cork,Fiber,Paper,Plushes,Polyester,Rubber,leather,Sponge etc.,
2.The cutting table size can be custom build according to the original material size .
3.The cutting force can custom build for the requirement for cutting works.
4.Material feed type can be choice :manual ,auto feed ,sliding table ,roller feed etc.,
5.Any other custom build machine upon the request.
| Model | GRB(C)-25,30,35,40,50,60,80,100,150,200,300,500 |
| Cutting Force | 25 tons to 500 tons |
| Cutting table Size | 1200*600mm to 2500mm*2500mm |
| Tension Distance | 50-230mm |
| Voltage | 220V,380V,480V etc., |
| Motor Power | 1.5Kw-22Kw |
| N.W(approx.) | 1500 -16500kg |
| G.W(approx.) | 1600-17500kg |
| Hydraulic Oil Quantiy | 200L |
| Color | Custom build |
| Feeding type | Custom build |
