movable beam press for Automotive components

Gerson movable beam press for Automotive industry:including Automotive components,seat ,seat cover ,foot mat etc.,

movable beam press for Automotive components
movable beam press for Automotive components

1.The upper receding beam or head can be moved forwards and backwards and the distance is fine adjustable for the convenience of placing cutting materials.
2.Cutting area same as the beam/head area ,so it is great for large cutting die.
3.The cutting material remains stationary during the receding cutting.
4.Larger head, bed and tonnage needs can be custom ordered.
5.From 35 tons to 400Tons cutting power for your choice.

Options

  • Sheet feeders
  • De-stackers
  • Sheeters
  • Knock-out stations
  • Pick and place load/unload
  • Edge tracking
  • Accumulators (lazy loop)
  • Auto tool change
  • Conveyors
Model Maximum Cutting power(ton) Area of work table(mm) Press Board Stroke      range Distance between upper pressing board and worktable Motor power Machine dimensions(mm) Net weight
GRH-35 350KN(35T) 1600*610mm 1600*600mm 0-110mm 60-160mm 3KW 2320*1400*1520mm 2400kg
GRH-500 500KN(50T) 1600*610mm 1600*600mm 0-110mm 60-160mm 4KW 2320*1600*1720mm 4000kg
GRH-80 800KN(80T) 1600*820mm 1600*800mm 0-120mm 60-180mm 4KW 2320*1600*1720mm 5500kg
GRH-120 1200KN(120T) 1600*820mm 1600*800mm 0-120mm 60-180mm 5.5KW 2320*1600*1720mm 6500kg

**Cutting Force more than 400 Tons or upwards can custom made.
**Cutting Bed more than 1600x800mm or upwards can custom made.
