Gerson movable beam clicker press is one of die cutting machinery that widely used in many industry:leather goods,shoes,packaging,auto parts,medical products,Carpet,Felt,paper board,cork,Flooring,floor pad,Craft Products,plastics,rubber,gasket Materials,electronics,textiles etc.,
There have movable swing beam clicker press and movbale full beam clicker press:
1.The above photo show one of movable swing beam clicker press that special for small material die cutting.
2.The press with movable beam can easily operated by double hand ,The movable beam size,cutting force and work table size have a varuety choice for different need.
3.Perfect operator visibility and excellent performance,very low noise.
4.The press work with any cutting die/knife/tool ,so that can cutting out any shapes to meet the production need.
5.Welcome to contact Gerson machinery for more details .gerson accept any requirement or custom build.
| Model | GR,GRA,GSB model |
| Maximum Cutting Force | 80-300 kn(more large cutting force ,please see the other model) |
| Cutting speed | 0.085m/s |
| Adjustable stroke | 5-180mm |
| Tension distance | 60-250mm |
| Cuttting table size | 800,900,1000,1200×400,500,610mm more |
| size | 660×780×1500mm or more |
| Motor Power | 0.75KW,1.1KW |
| Net Weight (N.W.) | 450Kgs-1100Kgs |
