Membrane Switches Die Cutting Machine is the special die cutitng machine for cutting Capacitive Touch Membrane Keypad , Lgf Backlight Membrane Switch , EL Lamp Backlight Membrane Keypad , PET or PC Membrane Switches,Graphic Overlay , Touch Screen ,PCB FPC Circuit Membrane Keypad, Domed Keys,Silicone Rubber Keypads etc.,
1.The Gerson die cutting machine can die cut out any shapes of Membrane Switches for your production requirement.
2.Gerson have many models for cutting out different size of Membrane Switches or similar products.
3. It is equiped with lubricating system, to reduce wear and prolong its service life.And machine is very easy to operate by the worker.
4.High speed and low energy consumption.
5.Any custom built ,please contact Gerson sales department.Gerson can design and build any die cutting machine based on your production requirement.
|
Model |
GR-20C |
GR-27C |
GR-27C/1 |
GR-27C/2 |
| Max. cutting power |
20 ton |
27 ton |
27 ton |
27 ton |
| Maximum stroke(mm) |
80 |
100 |
100 |
100 |
| Cutting table(mm) |
900 x 430 |
900 x 450 |
1000 x 500 |
1200 x 500 |
| Arm width(mm) |
370 |
370 |
500/600 |
500/600 |
| Motor power |
HP. 1 |
HP. 1,5 |
HP. 1,5 |
HP. 1,5 |
| Net weight with oil |
Kg. 570 |
Kg. 780 |
Kg. 840 |
Kg. 910 |
| Sizes about (mm) |
1000 x 900 |
900 x 1000 |
1000 x 1000 |
1200 x 1030 |
| Sizes sea packing(mm) |
1050 x 1085 |
1050 x 1150 |
1150 x 1150 |
1350 x 1180 |
| Gross weight and volume with sea packing |
Kg. 640 |
Kg. 900 |
Kg. 980 |
Kg. 1055 |
