Gerson die cutting machine have manual feed cutting machine and automatic feeding die cutting machine.
The manual feeding cutting machines are normal used for die cutting :Leather,rubber,fabric,plastic,paper,paperboard,cork ,wood etc,soft and semi-rigid material .
Gerson manual feeding cutting machine including the following cutting machine:
1.Gerson manual clicker press:
The manual clicker press have 5 ton and 6 ton mechanical clicker press and 8 ton to 28 ton hydraulic clicker press:
manual feed cutting machine
| Model | GSB-8/10,GSB-2C,GR,GRA |
| Maximum Cutting Force | 8Tons,10,12,14,15,16,18,20,22,25,27,28 ton |
| Cutting speed | 0.085m/s |
| Adjustable stroke | 5-180mm |
| Tension distance | 60-190mm |
| Cuttting table size | 650×330mm,900×430mm,1000×500mm |
| size | 660×780×1500mm to 1350×1180×1700mm |
| Motor Power | 0.75KW to 1.5Kw |
| Net Weight (N.W.) | 550Kgs to 1200kgs |
2.Gerson manual travelling head press
manual feed cutting machine
1.Die cut materials that are soft or rigid
2.Die cut materials in single or multiple layers
3.The cutting setting is simple,easy to operate.
4.All standard die constructions can be used – strip steel, wood forme or forged steel
5.Powered head traverse for effortless operation
6.Simple, accurate die setting and daylight adjustment
7.High reliablility ,low noise,low consuption.
8.Photocell front barrier for complete safety
9.Illuminated work area
10.Complete with high grade polypropylene cutting board, hydraulic oil and operating manual
| Model | GRT-25,30,40,50,60,80,100 |
| Max Cutting Force | 25 to 100 tons |
| Cutting table Widths | 1800~2500mm or more |
| Cutting Head/Movable trolley | 500 x 500mm up to 1000 x 1000mm |
| Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,co | |
3.Gerson manual beam cutting machine
manual feed cutting machine
1. Operate the structure of double cylinder and precise four-column automatic balancing links to make sure same cutting depth in each and every cutting region.
2. If the pressure plate presses downward to touch the die cutter, the appliance automatically slowly cuts, that make that there are no error involving the top and bottom layers of cutting materials.
3. Have setting structure especially, that makes adjustment of stroke safe and accurate coordinating with cutting force and cutting height.
4. Set automatic force feed to ensure the precision of machine and raise longevity of machine.
Applications:
From the smallest 25 Ton for the largest 500 Tons and up on request, Gerson Precise cutting machine are adaptable to some lots of applications. Suited to cutting many materials:Leather,rubber,fabric,plastic,paper,paperboard etc.,
| Model | GRB(C)-25T to 500T |
| Max cutting force(T) | From 25 Tons to 500 Tons |
| Distance between upper press board andworktable(mm) | 50-240 |
| Cutting area(mm) | 1250×600,700,800,900,1000,1200, 1500 |
| 1470×600,700,800,900,1000,1200, 1500 | |
| 1600×600,700,800,900,1000,1200, 1500 | |
| Motor power | 1.5 to 22KW |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
