Gerson manual clicker press is one of die cutting machine which is used for small pieces die cutting ,such as leather,fabric,plastic ,rubber,paper etc.,It is feeding by operator hand .
The manual clicker press have mini hand tabletop clicker press , mechanical clicker press and hydraulic clicker press.
1) mini hand tabletop clicker press:
It is the small type operated by your hand power. It is very easy operation.And can be cut most material by your hand .quick and reliable.Most important ,it is affordable .
Gerson can custom build the size to based on your material and cutting die.
This press can be for any common cutting die such as steel rule die ,steel die ,forged die etc.,Gerson also could make the die for you.
5.Custom build size welcome to contact us for further information.
| Model | Gerson GMB |
| Maximum Cutting Force | 0.5ton,1 ton ,2 ton,3 ton,4 ton,5ton |
| Cutting speed | based on your hand |
| Adjustable stroke | 12mm ,50mm or more |
| Tension distance | 10-100mm or more |
| Upper beam size | 200×100mm to 500mm×500mm |
| Cutting table size | 200×100mm to 500mm×500mm |
| Net Weight (N.W.) | 20Kgs to 200kgs |
Gerson have 5 ton and 6 ton small clicker press and 8 ton to 28 ton hydraulic clicker press:
2).5 ton and 6 ton small manul clicker press
| Model | MX-5T,MX-6T serials |
| Max cutting force(T) | 5-6T |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting table | 580×360,700×380 etc., |
| Based on your material and die | |
| Example: 500X400mm etc., | |
| Cutting Head | 330×450 to More |
| Motor power | 1.1kw,1.5kw |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 400 to 800 |
| 500 to 1000 |
3).8 ton and 10 ton small manul clicker press
1.Easy to operate with swing arm and button press.
2.Economic cost and stable working function.
3.Two hands switches operate to ensure the operator is safe and easy.
4.The position of the swing arm is adjusted by the upper handwheel on the top of clicking press,which can obtain the best cutting position ,which can increase work efficiency and prolong the service life of cutting dies and boards.
| Model | GSB,GR,GRA,GRB serials |
| Max cutting force(T) | 8Tons-500Tons or More |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting table | 650×330mm to 3000mm×2500mm |
| Based on your material and die | |
| Example: 1000X500mm etc., | |
| Cutting Head | 330×450 to More |
| Motor power | 0.75kw to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
The other bigger manual clicker press models have 10 ton,12 ton,14 ton,15 ton,16 ton,18 ton,20 ton,22 ton,25 ton,27 ton,28 tons.
