Leather travelling head press

travelling head press for  leather material cutting including Artificial Leather and Genuine Leather .Geson moving head press is really the
next upgrade of Swing Beam Press for cutting single or multi shapes material from rolls or sheets.

1.Manual Travelling Head Press:The travelling head cutting

Leather travelling head press
Leather travelling head press

controlled by two hand .
2.Automatic Travelling Head Press:Gerson can make fully automatic cutting system avaliable including feeding, cutting, knock-out and stacking system make high productive.

Leather travelling head press
Leather travelling head press
Model GRM(A)-25T to 200T
Max cutting force(T) From 25 Tons to 200 Tons
Range between working table 50-240mm (Upper to Bottom Table)
Stroke Adjustment 0-170mm
Cutting table width(mm) 1800~2500mm or more
Based on your material and die
Example: 1600X600mm etc.,
Cutting Head Movable trolley 500×500 to 1000x1000mm
Motor power 3kw to 22KW
Electric Power 220V/380V/415V,50-60hz etc.,
Machine Net weight (KG) 1600 to 16500
1700 to 17500

Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
