Gerson cutting machine for most leather bag including leather handbag ,purses, totes, clutches etc.,
For the cutting small leather pieces ,you could take clicker press model GSB,GRA,GR serial The table size is about 900mm*400mm,900mm*430mm,1000mm*500mm etc.,The cutting force is from 8Ton ,10 Tons, 12 tons,14Tons,18 tons,20Tons,22Tons, 2/27/28Tons etc.,
Feature:
1. The above cutting machine is applicable to cutting of various nonmetal materials by cutting die.
2. The oil way system specially designed can conveniently adjust the rocker height. No adjustment is needed after the height of die cutter is changed.
3.High speed and low energy consumption. It can output the cutting force of 8T and 25T.
So if you want to find one right cutting machine for your production.Please contact us .
| Model | GSB-8/10,GSB-2C,GR,GRA |
| Maximum Cutting Force | 8Tons,10,12,14,15,16,18,20,22,25,27,28 ton |
| Cutting speed | 0.085m/s |
| Adjustable stroke | 5-180mm |
| Tension distance | 60-190mm |
| Cuttting table size | 650×330mm,900×430mm,1000×500mm |
| size | 660×780×1500mm to 1350×1180×1700mm |
| Motor Power | 0.75KW to 1.5Kw |
| Net Weight (N.W.) | 550Kgs to 1200kgs |
