Die Cutting Machine
38 Years+ Manufacturer
Quote Now

industrial die cut press machinery

This die cut press machinery can be used for many industrial production,such as footwear,bag,dress,textile,rubber industry etc.,

industrial die cut press machinery
industrial die cut press machinery

Usage: mainly used for cutting leather soft plastic, rubber, fiber, cotton fabric, paperboard ,textile and other similar materials with cutting die.

Feature:
1. The die press machine body are cast iron with firm structure and light weight.
2. It is provided with automatic lubricating system to lessen abrasion and prolong service life.
3. Double hands operation function guarantee the safety of operators.
4. Double-direction oil way design provides stability and reliability.

Model GRB(C)-25T to 500T
Max cutting force(T) From 25 Tons to 500 Tons
Range between working table 50-240mm (Upper to Bottom Table)
Stroke Adjustment 0-170mm can be customized
Cutting area(mm) (500-3000)X(1000-3000)mm
Based on your material and die
Example: 1600X600mm etc.,
Motor power 1.5 to 22KW
Electric Power 220V/380V/415V,50-60hz etc.,
Machine Net weight (KG) 1600 to 16500
1700 to 17500
