Gerson hydraulic cutting machine with turning arm is one of die cutting machine that manufactured for most small or medium parts from the soft and semi-hard material .
1.This hydraulic cutting machine can di cut for leather material such as glove ,shoes,bags,saddle etc.,fabric material ,paper,rubber,foam ,plastic sheet etc.,
2.The machine is very easy for operation by hands:Just put the original material on the cutting pad(PP plastic board) ,then positions dies on material .Using upper turning arm can move horizontally easily to over dies to cut out parts from the material.
3.Double hand operated required when cutting that make the safety for operator.
4. High stable hydraulic system that ensures proper lubrication and extending the life of the machine .Any standard hydraulic oil such as #46 can be useing in this machine.
5.More cutting force and cutting area size and special request for production can custom built .
| Model | GSB,GR,GRA,GRB serials |
| Maximum Cutting Force | 8Tons-500Tons or More |
| Cutting speed | 0.085m/s |
| Adjustable stroke | 5-300mm or more |
| Tension distance | 60-350mm or more |
| Cuttting table size | 650×330mm to 3000mm×2500mm |
| size | 660×780×1500mm to 2800×3200×1700mm |
| Motor Power | 0.75KW to 22Kw |
| Net Weight (N.W.) | 550Kgs to 18000kgs |
