Hydraulic conveyor belt feed traveling head cutting machine is the special die cutting machine with automatic conveyor belt feed the material into the traveling head cutting bed ,Then the traveling head descend to cut out the material by the cutting die or molds.
1.It is aotmatic feed based on your material size and cutting out size .sSo we designed the cutting area and cutting force based on your production requirement.
2.The material can die cut out such as leather, fabric, foam, EVA, rubber gasket, plastic etc.
3.The machine have using 4-column Beam for Cutting with double cylinder and autoamtic balancing system all these to make sure long time using of the die cutting machine.
4.Gerson have built and manufactured lots of or hydraulic conveyor belt feed die cutting machine or any similar machinery .If you want to find a die cutting machine,die cutitng press and hydraulic press or want to do business ,welcome to contact us for further information.
Model | GRM(A)-25T to 200T |
Max cutting force(T) | From 25 Tons to 200 Tons |
Range between working table | 50-240mm (Upper to Bottom Table) |
Stroke Adjustment | 0-170mm |
Cutting table width(mm) | 1800~2500mm or more |
Based on your material and die | |
Example: 1800X600mm etc., | |
Cutting Head
Movable trolley |
500×500 to 1000x1000mm |
Motor power | 3kw to 22KW |
Electric Power | 220V/380V/415V,50-60hz etc., |
Machine Net weight (KG) | 1600 to 16500 |
1700 to 17500 |
Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
