Honeycomb paper die cutting machine

Honeycomb paper die cutting machine is manufactured and designed by Gerson ,that die cutting  honeycomb paperboards ,Honeycomb paper or any similar material.

 Honeycomb paper die cutting machine

Honeycomb paper die cutting machine

1.This honeycomb paper cutting machine can die cut out any shapes of honeycomb paper board by the cutting die/knife/tool.The cutting die/knife/toll can mount under the beam or on the sliding tray/table.

2.Using high quality hydraulic driven system ,double oil cylinder and four strong column that  can guarantee the cutting accuracy.

3. Automatic lubricating system that make sure the high die cutting precision and machine long using life.

4.The machine have mnual feed or automatic sliding tray/table system that increase the production volumn.

5.Any special specification such as the cutting pressure ,cutting table size,feed system can be customized.

Model GRB(C)-25T to 500T
Max cutting force(T) From 25 Tons to 500 Tons
Range between working table 50-240mm (Upper to Bottom Table)
Stroke Adjustment 0-170mm
Cutting area(mm) (500-3000)X(1000-3000)mm
Based on your material and die
Example: 1600X600mm etc.,
Motor power 1.5 to 22KW
Electric Power 220V/380V/415V,50-60hz etc.,
Machine Net weight (KG) 1600 to 16500
1700 to 17500
