High speed belt type CNC rotary die cutting machine

High speed belt type CNC rotary die cutting machine is CNC die cutting machine made by Gerson .Which is special die cutting machine manfuactured in China.

High speed belt type CNC rotary die cutting machine
High speed belt type CNC rotary die cutting machine

The machine is used for die cutting non-metal material such as fabric leather, foamed PVC / EVA, self-adhesive, plastic / rubber sheet, intermediate or soft sheet or roll material.,

The most productive cutting press with more than 100 strokes per minute.
The belt and pincher feeding system ensures a perfect material feeding and a very high cutting precision,both for rolls in multiple layers as well as for sheets.
The automatic nesting program guarantees an extremely high yield for big material saving.
A user friendly software interface allows everybody to operate on the machine, even unskilled employees.
Available in two configurations for different material cutting widths.

Model GRM(A)-25T to 200T
Max cutting force(T) From 25 Tons to 200 Tons
Range between working table 50-240mm (Upper to Bottom Table)
Stroke Adjustment 0-170mm
Cutting table width(mm) 1800~2500mm or more
Based on your material and die
Example: 1600X600mm etc.,
Cutting Head



Movable trolley

500×500 to 1000x1000mm
Motor power 3kw to 22KW
Electric Power 220V/380V/415V,50-60hz etc.,
Machine Net weight (KG) 1600 to 16500
1700 to 17500

Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
