GSB clicker press with swing arm

GSB clicker press with swing arm is die cutting press machine built by Gerson machinery.It is very porpular used in many industries .It is great for die cutting out the small parts from paper,rubber,foam,plastic,leather,fabric etc.,

GSB clicker press with swing arm
GSB clicker press with swing arm

1.  High speed, little waste of energy, rigid structure, simple operation.

2. Self-acting height setting mechanism: no extra adjustment is needed.

3. Large daylight makes for easier operation, which saves a lot of time.

4. High reliability: ergonomic both-hand operation design.

5. Customization concerning cutting table, cutting force, upper press board can be easily satisfied.

6. Warranty period: 1 Year

Model GSB-10/12/14/15/16/18/20/25
Cutting Force 10,12,14,15,16,18,20,25 Tons
Sway Arm Width 330X450mm,350X450mm,450X550mm
Stroke Adjustment 5-75mm
Distance Between Upper Table And Lower Table 60-140mm
Table Area 900X400mm,1000X500mm
Electric Supply Voltage 3×440/415/400/380 /220V, 50/60 Hz
Motor Power 0.75kw,1.1kw,1.5Kw
Packing Size(LXWXH) 1100X1100X1700mm
Weight 500Kg/650kg/1000kg/1100kg
Hydraulic oil (46#) 50 Liters
