Four Post Hydraulic Beam Cutting Press

Gerson four post hydraulic beam cutting press is beam cutting press that widely used for cutting industry such as Abrasive,Automotive,Clothing,Foam,Gasket,General Die Cutting,Medical,Textile,Toys Games and Sports.

Four Post Hydraulic Beam Cutting Press
Four Post Hydraulic Beam Cutting Press

1.Compared to the swing arm clicker press and traveling head press ,The advantage of beam cutting press is between the cutting surface and the upper beam where it is possible to use very large cutting dies, in theory as large as the cutting platen.
2.Four column, twin cylinder construction and Double mechanical balancing system
3.The mechanical balancing system ensures that the maximum cutting force of the press can be delivered anywhere on the bed of the press, and keeps the bed and bridge parallel even under asymmetrical (unbalanced) loads. This hydraulic press can deliver its total force at any point in the down stroke.
4.This beam pres can be for die cutting Foam, textiles, and plastics,Rubber, packings, and vinyl
Leather, composites, and fiberglass,Vinyl and carpet floor tiles,Cork, wood, and gasket materials
Filters, abrasives, and shoe components,Electrical insulation, medical supplies, and sponges,luggage, toys, etc
5.Type equipment:Single or Double Sliding Work Tray ,Automatic Belt Feed,Belt Conveyor etc.,
6.Any speical requirement ,welcome contact Gerson .

Model GRB(C)-25,30,35,40,50,60,80,100,150,200,300,500
Cutting Force 25 tons to 500 tons
Cutting table Size 1200*600mm to 2500mm*2500mm
Tension Distance 50-230mm
Voltage  220V,380V,480V etc.,
Motor Power 1.5Kw-22Kw
N.W(approx.) 1500 -16500kg
G.W(approx.) 1600-17500kg
Hydraulic Oil Quantiy 200L
 Color Custom build
Feeding type Custom build
