Fabric cutting machine

Gerson fabric cutting machine is die cutting machine for die cutting fabric .Gerson machinery can be for cutting including:Cotton Fabric, Wool Fabric ,Linen / Ramie / Hemp Fabric, Silk Fabric,Bamboo Fabric ,Leather Polyester Fabric ,Nylon Fabric,T/C Fabric, T/R Fabric, Grey Fabric, Knitted Fabric,Printed Fabric,Jacquard Fabric, Embroidered Fabric, Denim Fabric,Satin Fabric, Taffeta Fabric ,Functional Fabric, Non-woven Fabric, Stretch Fabric, Blended Fabric etc.,

Fabric cutting machine
Fabric cutting machine

One.For small size of fabric ,Gerson clicker press  is a die cutting machine that cuts shapes out of fabric with cutting dies.

1.Easy to operate with swing arm and button press.
2.Economic cost and stable working function.
3.Two hands switches operate to ensure the operator is safe and easy.
4.The position of the swing arm is adjusted by the upper handwheel on the top of clicker press,which can obtain the best cutting position ,which can increase work efficiency and prolong the service life of cutting dies and board.

Model GSB-8/10,GSB-2C,GR,GRA
Maximum   Cutting Force 8Tons,10,12,14,15,16,18,20,22,25,27,28 ton
Cutting speed 0.085m/s
Adjustable stroke 5-180mm
Tension distance 60-190mm
Cuttting table size 650×330mm,900×430mm,1000×500mm
size 660×780×1500mm to 1350×1180×1700mm
Motor Power 0.75KW to 1.5Kw
Net Weight (N.W.) 550Kgs to 1200kgs













Two.For small and medium size of dies,Gerson traveling head press is die cutting machine with movable head.There have two kinds :manual traveling  head press and automatic CNC traveling head press.

1.Both for cutting soft or semi-rigid in single layer or multiple layers.
2.Cutting head left and right together with the cutting dies ensures the clear view over the table.
3.Fully automatic cutting system available including feeding, cutting, knock-out and stacking system make high productive.
5.Large cutting bed with 500*500 mm trolley or 600*600 or 1000 mm *1000 mm trolley or more wide trolley ,Any size trolley can custom made.
6.From 25T to 100T cutting force for choice or can custom made.
7.Special custom design or specifications welcome.

Model GRMA-25,30,40,50,60,80,100
Max Cutting Force 25 to 100 tons
Cutting table Widths 1800~2500mm or more
Cutting Head/Movable trolley 500 x 500mm up to 1000 x 1000mm
Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc

Three.For big size of fabric ,Gerson beam press is full head die cutting machine .

1. Operate the structure of double cylinder and precise four-column automatic balancing links to make sure same cutting depth in each and every cutting region.
2. If the pressure plate presses downward to touch the cutting dies, the appliance automatically slowly cuts, that make that there are no error involving the top and bottom layers of cutting materials.
3. Have setting structure especially, that makes adjustment of stroke safe and accurate coordinating with cutting force and cutting height.
4. Set automatic force feed to ensure the precision of machine and raise longevity of machine.
Applications:
From the smallest 25 Ton for the largest 500 Tons and up on request, Gerson Precise cutting machine are adaptable to some lots of applications. Suited to cutting many materials:Leather,rubber,fabric,plastic,paper,paperboard etc.,

Feed Systems Available: Hand Placed Material
Roll Feed Systems
Clamp Feed Systems
Single and Dual Sliding Tables
Manual and Powered Tables

Custom special requirement are available upon request.

Model GRB(C)-25T to 500T
Max cutting force(T) From 25 Tons to 500 Tons
Distance between upper press board andworktable(mm) 50-240
Cutting area(mm) 1250×600,700,800,900,1000,1200, 1500
1470×600,700,800,900,1000,1200, 1500
1600×600,700,800,900,1000,1200, 1500
Motor power 1.5 to 22KW
Machine Net weight (KG) 1600 to 16500
1700 to 17500
