EVA Foam Cutting Machine

EVA foam cutting machine is good at die cutting machinery for magic sponge eraser, melamine foam eraser, foam magic eraser, EVA felt eraser and many other similar materials.

EVA Foam Cutting Machine
EVA Foam Cutting Machine

1. This machine has a great advantage that it has a large cutting table, which brings great convenience to die cutting operation of large-sized materials.

2. The cutting machine works with cutting dies. Our company can specially make machine3 along with dies for you.

3. It is convenient to set the cutting depth. As a result, the cutting result is very precise. Because both-hand operation is required, there is no need to worry about the safety of the operators.

4. Feed type consisting of manual and automatic and feed device including sliding tray, belt etc. can be optionally installed.

5. This machine can die cut most non-metal materials such as leather, fabric, plastic and rubber.

6. There is nearly no limit to cutting force and table size and we accept customization. Welcome to contact us if you are in need.

Model GRB(C)-25T to 500T
Max cutting force(T) From 25 Tons to 500 Tons
Range between working table 50-240mm (Upper to Bottom Table)
Stroke Adjustment 0-170mm
Cutting area(mm) (500-3000)X(1000-3000)mm
Based on your material and die
Example: 1600X600mm etc.,
Motor power 1.5 to 22KW
Electric Power 220V/380V/415V,50-60hz etc.,
Machine Net weight (KG) 1600 to 16500
1700 to 17500
