Die stamping press

Gerson die stamping press is die cutting press machine tool used to shape or cut soft and semi-rigid material by cutting  it with a die.

Die stamping press
Die stamping press

1.The die stampomg press can die cut the material such as leather ,fabric,foam,paperboard,plastic,rubber etc.,

2.There have two kinds of die stamping press designed by Gerson machinery.one is mechanically driven die stamping presses and hydraulically driven die stamping presses.The most common mechanical presses use an eccentric drive to move the press’s ram.whereas hydraulic cylinders are used in hydraulic presses.

3.Also the machine can be feed by hand feed or feed table/conveyors for progressive cutting,material feed rollers,Extended Tray Feed System etc.,

4.Various machine model in cluding different table size ,die stamping force ,feed type for choice.

5.Any special requirement for production,welcome to contact Gerson Machinery.

Model GR,GRA,GRM,GRB serials
Maximum   Cutting Force 8Tons-500Tons
Cutting speed 0.085m/s
Adjustable stroke 5-300mm or more
Tension distance 60-350mm or more
Cuttting table size 650×330mm to 3000mm×2500mm
size 660×780×1500mm to 2800×3200×1700mm
Motor Power 0.75KW to 22Kw
Net Weight (N.W.) 550Kgs to 18000kgs
