This die cutting machine is used to die cut foam or sponge for most magic cleaning foam,sponge factories. or the factories produce magic eraser, cellulose sponge, bath sponge, cleaning sponge, car cleaning sponge, packaging sponge, cosmetic sponge, special sponge for industrial usage and so on.
1.Double fuel tanks and precision four-column self-balancing linkage guarantees the uniform cutting depth of each cutting position.
2.There is no failure to full cutting or flash phenomenon when cutting eco-friendly materials for pressure stabilization.
3. Precise cutting balance can effectively reduce the loss of cutting die and cutting plate.
4. PLC programmable control, bilateral motor automatic feeding mechanism.
5. Registration precision reaches ±0.2mm due to variable frequency buffer system.
6. The micro-inching equipment of cutting board enables that each cut will not be in the same location to ensure good cutting edge effect.
7.Accept customized requirement .
| Model | GRB(C)-25T to 500T |
| Max cutting force(T) | From 25 Tons to 500 Tons |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting area(mm) | (500-3000)X(500-3000)mm |
| Based on your material and die | |
| Example: 1600X700mm etc., | |
| Motor power | 1.5 to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
Gerson can make die cutting machine press according to your specifical requirement :such as cutting force power,worktable size,motor,feeding type etc.,
