Die cut-outs machine

Gerson machinery is large company in die cutting machine technology has been achieved through more than 20 years experience in design and manufacture.

Gerson die cut-outs machine is for cut-outs the shapes of  the sheet or roll material .It is for die cut leather,fabric,fiber,panel,rubber,plastic,foam etc.,The material placed on the base of the Gerson cut-outs machines and die is above the material to cut through .

Gerson die cut-outs machines have from 5 tons to 500 tons cutting force for differenet requirement .

Gerson 5 tons to 30 tons for small to medium pieces cut-outs .

Die cut-outs machine
Die cut-outs machine
Model GSB-8/10,GSB-2C,GR,GRA
Maximum   Cutting Force 8Tons,10,12,14,15,16,18,20,22,25,27,28,30 ton
Cutting speed 0.085m/s
Adjustable stroke 5-180mm
Tension distance 60-190mm
Cuttting table size 650×330mm,900×430mm,1000×500mm
size 660×780×1500mm to 1350×1180×1700mm
Motor Power 0.75KW to 1.5Kw
Net Weight (N.W.) 550Kgs to 1200kgs













Gerson 25 tons to 500 tons cutting force die cut-outs machines for big area .

The main machine is controlled by four-column guiding, double-crank balancing, four-column blocking fine-adjustment mechanism and hydraulic control system, which can guarantee the speed and accuracy of die cutting of machine.Gerson machinery accept Custom design and manufacturing accordign to request.

die-cut-outs-machines

Model GRBC-25T to 500T
Max cutting force(T) From 25T to 500
Distance between upper press board andworktable(mm) 50-240
Cutting area(mm) 1250×600,700,800,900,1000,1200, 1500
1470×600,700,800,900,1000,1200, 1500
1600×600,700,800,900,1000,1200, 1500
Motor power 1.5 to 22KW
Machine Net weight (KG) 1600 to 16500
1700 to 17500
1800 to 18500
