Conveyor belt feeding hydraulic die cutting machine

Conveyor belt feeding hydraulic die cutting machine perfectly satisfies the needs of cutting plastic, rubber, leather and the similar low-rigid machine.

Conveyor belt feeding hydraulic die cutting machine
Conveyor belt feeding hydraulic die cutting machine

Key Feature

  1. More than one cylinder can be connected perfectly by the aid of superior connection set, 2 oil cylinders and 4-column structure.
  2. High accuracy and longer working life can be achieved by lubrication autoragulation mechanism.
  3. The conveyor made of nylon is preeminent enough to undertaker the task to inlet, outlet and serve as the cutting platform.
  4. Interchangeable cutting size and force will cater to different needs.
  5. Special specifications can be satisfied by our long-term practice, creditable quality and good prestige.
Model No GRBC-100 GRBA-120 GRBA-150 GRBA-200-500
Cutting force 100 Tons 120 Tons 150 Tons 200-500T tons
Travel adjustment range 0-200mm
Range between the working tables 80-280mm
Size of cutting area 1680*1120mm  or 1480*1120mm
Motor power 7.5kw 11kw 11kw 11kw/15Kw
Net weight        4500kgs  4800kgs 5500kgs 7500kgs
Gross weight         4700kgs  5000kgs 5750kgs 7800kgs
Dimension 2500*1800*2000mm 2700*1800*2000mm
Automatic grade  Automatic
Hydraulic oil 46# or 68#
Electronic supply 3 phase 50hz or 60hz  380V 440V    or as optional
Machine color Can custom built
