CNC clicker press is the CNC computer numerical control type die cutting press manufactured by Gerson machinery.
1.CNC clicker press with auotoamtic feeding the material and continious die cutting controled by CNC.It is good for bulk production .
2.CNC clicker press can be for cutting soft or semi-rigid in single layer or multiple layers.
3.CNC clicker press can be feeding in sheet material or roll material .
4.Gerson have CNC traveling head clicker press and CNC full beam head clicker press .
5.Both CNC traveling head clicker press and CNC full beam head clicker press can custom build for any production requirement.More information ,please contact Gerson directly.
| Model | GRM(A)-25T to 200T |
| Max cutting force(T) | From 25 Tons to 200 Tons |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting table width(mm) | 1800~2500mm or more |
| Based on your material and die | |
| Example: 1600X600mm etc., | |
| Cutting Head
Movable trolley |
500×500 to 1000x1000mm |
| Motor power | 3kw to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
Gerson can make the CNC clicker press with automatic feedingaccording to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
