Gerson CNC beam press is beam press with CNC controlled.This die cutting machine is for medium and large area material including leather,fabric,fiber,plastic,rubber,paper,cork etc.,
This model automatic feeding system,PlC controlled,automatic cutting setting ,The cutting pressure from 30T to 500T or more.Accept custom design and manufacturing.
CNC Beam press including CNC movable beam press,full beam press etc.,
1.PLC controlled, with simple, prompt and accurate operation.The frequency conversion buffering and PLC control system make the positioning precision reach ±0.02mm.
2. The main machine structure of double cylinder and precise four-column automatic balancing links to make sure same cutting depth in each and every cutting region.
3. The pressing board carries out slow cutting when it presses downward to contact the die cutter, which can make that there is no size error between the uppermost layer and lowermost layer of cut materials.
4. Double-side automatic feeding system can be allocated to enhance the production efficiency of machine twice or thrice.Die cutters of different height can be set at both sides with high working efficiency.Can be feeding in rolls or sheets.Set automatic force feed to ensure the precision of machine and raise longevity of machine.
5. Independent stroke or daylight setting for each side can be cut different height cutting dies for each side.
6. Cutting dies pneumatic clamp device can be allocated to make the replacement of die cutter convenient and prompt.
| Model | GRBA-25(30) | GRBA-35(40) | GRBA-50 | GRBA-60 | GRBA-80 | GRBA-100 | GRBA-150(200) | GRBA-300(400,500) |
| Max cutting force(T) | 25T,30T | 35T,40T | 50T | 60T | 80T | 100T | 150T, 200T | 300T,400T.
500T or more |
| Distance between
upper press board and worktable(mm) |
50-180 | 50-240 | 50-240 | 50-240 | 50-240 | 50-240 | 50-240 | 50-240 |
| Cutting area(mm) | 1250×500 | 1250×6001250×710 | 1250×800 | 1250×800 | 1250×800 | 1250×900 | 1250×1000 | 1250×1500 |
| 1470×500 | 1470×6001470×710 | 1470×800 | 1470×800 | 1470×800 | 1470×900 | 1470×1000 | 1470×1500 | |
| 1600×500 | 1600×6001600×710 | 1600×800 | 1600×800 | 1600×800 | 1600×900 | 1600×1000 | 1600×1500 | |
| Motor power | 1.5KW | 3KW | 4KW | 5.5KW | 7.5KW | 7.5KW | 11KW | 22KW |
| Electric SupplyVoltage | 3 phases x440/415/400/380/220/200V, 50/60 Hz | |||||||
| Machine Net weight (KG) | 1600 | 1900,2000 | 3000 | 4300 | 6200 | 7100 | 9000 | 16500 |
| 1700 | 2100,2200 | 3300 | 4600 | 6600 | 7600 | 9500 | 17500 | |
| 1800 | 2300,2400 | 3600 | 4900 | 7200 | 8100 | 10000 | 18500 | |
| Gerson could design and manufacture according to customer production requirement. | ||||||||
