Clicker machine

Geson clicker machine known as clicker press which is for die cutting small or medium pieces of soft and semi-rigid material including rubber,leather,paper,cloth,cardboard,cork,foam etc.,

Clicker machine
Clicker machine

1. cutting machine adopts the latest Italian circuit design, optimized hydraulic system, can easily adjust the height of the swing arm to change the die height, without any adjustment.
2. Easy operation, simple, low failure rate, and no traditional cutting machine noise, less failure, easy maintenance.
3. The upper and lower work surface smooth precision to ensure that each cutting point is affected by the same force. Avoid uneven layers.
4. using the electronic timer control stroke lower limit position, easy access to the best cutting position, high precision, high speed, low energy consumption.
5. Rocker-type cutting head rotates freely, the best line of sight operation, choice of materials to facilitate increased efficiency.
6. the special material cutting head with lubrication system and prolong life, but finding the best results.
7. Worker can use the double-sided sharp cutting knife or die, saving labor and die and plate costs.
8 using the hand wheel adjustment arm subtalar cut stroke, smooth and easy adjustment and simple operation.
9. hands button before the next feeding, and no continuous and disadvantages, safe.

Model GSB-8/10,GSB-2C,GR,GRA
Maximum   Cutting Force 8Tons,10,12,14,15,16,18,20,22,25,27,28,30 ton
Cutting speed 0.085m/s
Adjustable stroke 5-180mm
Tension distance 60-190mm
Cuttting table size 650×330mm,900×430mm,1000×500mm
size 660×780×1500mm to 1350×1180×1700mm
Motor Power 0.75KW to 1.5Kw
Net Weight (N.W.) 550Kgs to 1200kgs
