Traveling head clicker die press
1.Both for cutting soft or semi-rigid in single layer or multiple layers.
2.Cutting head left and right together with the cutting dies ensures the clear view over the table.
3.Fully automatic cutting system avaliable including feeding, cutting, knock-out and stacking system make high productive.
5.Large cutting bed with 500*500mm trolley or 600*600trolley or more wide trolley ,Any size trolley can custom made.
6.From 25T to 100Tcutting force for choice or can custom made.
7.Special custom design or specifications welcome.
| Model | GRM(A)-25T to 200T |
| Max cutting force(T) | From 25 Tons to 200 Tons |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting table width(mm) | 1800~2500mm or more |
| Based on your material and die | |
| Example: 1600X600mm etc., | |
| Cutting Head Movable trolley | 500×500 to 1000x1000mm |
| Motor power | 3kw to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
Gerson clicker die press is die cutting machine for small and medium size die cutting:Leather ,foam,PVC,plastic,rubber,paper,paperboard,fabric etc.,
Gerson have swing arm clicker die press and traveling head clicker die press:
1.Easy to operate with swing arm and button press.
2.Economic cost and stable working function.
3.Two hands switches operate to ensure the operator is safe and easy.
4.The position of the swing arm is adjusted by the upper handwheel on the top of clicker press,which can obtain the best cutting position ,which can increase work efficiency and prolong the service life of cutting dies and board.
| Model | GSB,GR,GRA,GRB serials |
| Max cutting force(T) | 8Tons-500Tons or More |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting table | 650×330mm to 3000mm×2500mm |
| Based on your material and die | |
| Example: 1000X500mm etc., | |
| Cutting Head | 330×450 to More |
| Motor power | 0.75kw to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
Gerson can make the cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,etc.,
