Clicker Die cutter

Gerson clicker die cutter is die cutting machine for cutting fabric, gaskets, rubbers, leather, vinyl, paper,plastics, diapers, carpet, lab grown human skin, body bags, medical devices etc.,

 Clicker Die cutter

Clicker Die cutter

Gerson clicker die cutter cutting force have from 8 tons to 30 tons .Normal cutting table size from 650×330mm to 1000×500mm.

Gerson accept custom build clicker press .

1.Easy to operate with swing arm and button press.
2.Economic cost and stable working function.
3.Two hands switches operate to ensure the operator is safe and easy.
4.The position of the swing arm is adjusted by the upper handwheel on the top of clicking press,which can obtain the best cutting position ,which can increase work efficiency and prolong the service life of cutting dies and board

Model GSB-8/10,GSB-2C,GR,GRA
Maximum   Cutting Force 8Tons,10,12,14,15,16,18,20,22,25,27,28,30 ton
Cutting speed 0.085m/s
Adjustable stroke 5-180mm
Tension distance 60-190mm
Cuttting table size 650×330mm,900×430mm,1000×500mm
size 660×780×1500mm to 1350×1180×1700mm
Motor Power 0.75KW to 1.5Kw
Net Weight (N.W.) 550Kgs to 1200kgs
