China clicker press

Gerson machinery as a leading technology leader clicker press and die cutting machine in China. Gerson have designed and manufactured many models for different industry usage.

A clicker press is die cutting machine that cuts shapes out of sheets or rolls of soft material and semi-rigid material, such as leather,fabric,paper,plastic,rubber etc, The clicker press need use a clicker press die .

The clicker press application industries:

Leather: leathergoods ,shoe uppers, wallets, purses, belts,shoes, insoles, insole socks, uppers, straps
Paper:  stationery, novelties, filters, labels,Insulation materials,card
Plastics:PVC binders, lampshades, stationery products, gifts,novelties, gaskets,felt, PTFE,electronic components, flexible PCB’s touch pads, button covers, legend plates
Rubber:gaskets, seals, washers,mats
Textiles:sample swatches and pattern books, underwear and outerwear components, hats, ties,Clothing components for hats, ties, collars, shoulder pads, soft toys, advertising novelties, mini jig-saw puzzles and more, carpets and flooring,Felt strips, washers, gaskets,,Automotive components
Cork wood: gaskets and mats
Foam and sponge : gaskets, packaging, consumer products, inserts, card, promotional products, blister packs
Others:Filters for machinery, breathing apparatus and the medical industry

1.swing arm clicker press GR model

swing arm die cutter 20 and 27 tons

Model

GR-20C

GR-27C

GR-27C/1

GR-27C/2

Max. cutting power

ton. 20

ton. 27

ton. 27

ton. 27

Maximum stroke(mm)

80

100

100

 100

Cutting table(mm)

 900 x 430

 900 x 450

1000 x 500

1200 x 500

Arm width(mm)

 370

370

500

500

Motor power

HP. 1

HP. 1,5

HP. 1,5

HP. 1,5

Net weight with oil

Kg. 570

Kg. 780

Kg. 840

Kg. 910

Sizes about (mm)

 1000 x 900
h. 935

900 x 1000
h. 1370

1000 x 1000
h. 1370

 1200 x 1030
h. 1370

Sizes sea packing(mm)

1050 x 1085
h. 1500

1050 x 1150
h. 1570

1150 x 1150
h. 1570

1350 x 1180
h. 1570

Gross weight and volume with sea packing

Kg. 640
m1,7

Kg. 900
m1,90

Kg. 980
m2,10

Kg. 1055
m2,50

1.swing arm clicker press GRA model

Model Maximum Cutting power(ton) Area of work table(mm) Swaying arm width Cutting table Motor power Machine dimensions(mm) Net weight(with oil) Gross weight
GRA-220 216KN(22Ton) 900×430 370mm 90mm 0.75Hp 900×850×h1400 650kg 750kg
GRA-270 264.6KN(27Ton) 1000×500 370mm 90mm 1.1Hp 1000×1050×h1410 850kg 900kg

3. clicker press GSB model

clicking die press machinery

Model GSB-2C/12/14/15/16/18/20/25
Cutting Force 12,14,15,16,18,20,25 Tons
Sway Arm Width 330X450mm,350X450mm,450X550mm
Stroke Adjustment 5-75mm
Distance Between Upper Table And Lower Table 60-140mm
Table Area 900X400mm,1000X500mm
Electric Supply Voltage 3×440/415/400/380 /220V, 50/60 Hz
Motor Power 0.75kw,1.1kw,1.5Kw
Packing Size(LXWXH) 1100X1100X1700mm
Weight 500Kg/650kg/1000kg/1100kg
Hydraulic oil (46#) 50 Liters
