Cellulose Acetate die cutting machine is the die cutting machine for punching or stamping out cellulose acetate sheet or cellulose acetate Membrane or cellulose acetate polymer film which can be used in as a component coatings, and as a frame material for eyeglasses; it is also used asa synthetic fiber in the manufacture of cigarette filters and playing cards etc.,.
The machine can be die cutting one layer or several layer of such material as plastic sheet roll, rubber sheet (bottom sole, medium sole), EVA, leather, plastic canvas, vacuum foaming products, nylons, carpet, mat, corks, soft tiles, paper boards and synthetic materials etc.,
The machine using hydraulic system which is designed and manufactured by Gerson that have many years experience in die cutting solution.The machine is for low noise, optimum efficiency, and low electricity consumption.
The machine can feed sheet or roll material in manual or automatic or autoamtic pickup system .All it is depending on your request.
The machine can custom built based on production requirement ,such as custom table ,feed table ,cutting table ,feed distance ,cutting speed ,hydraulic force etc.,
welcome to contact us at any time by email to our sales department.
| Model | GRB(C)-25T to 500T |
| Max cutting force(T) | From 25 Tons to 500 Tons |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting area(mm) | (500-3000)X(500-3000)mm |
| Based on your material and die | |
| Example: 1600X600mm etc., | |
| Motor power | 1.5 to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
