Key Feature
1. The operation is rather convenient. Normal dies made of strip steel, wood formed or forged steel can be adopted by the machine. Whether they are fixed on the upper board, on the table blade or on the material can be decided as appropriate.
2. No matter the materials are in sheet or roll, they can be perfectly cut even in several layers.
3. The machine has a distinguished strength that both sides can be equipped with manual work table or automatic motorized sliding table. They are controlled by independent system and has individual die setting on each tray for the largest output.
4. What’s more, the feed devices including feed table/conveyors for progressive cutting, material feed rollers, extended tray feed system etc. can be optionally installed.
5. Cutting pressure can range from 25T to 500T and the cutting table is measuring 1250*500, any larger ones can be customized.
6. We will spare no efforts to meet your expectations.
Model | GRB(C)-25T to 500T |
Max cutting force(T) | From 25 Tons to 500 Tons |
Range between working table | 50-240mm (Upper to Bottom Table) |
Stroke Adjustment | 0-170mm can be customized |
Cutting area(mm) | (500-3000)X(1000-3000)mm |
Based on your material and die | |
Example: 1600X600mm etc., | |
Motor power | 1.5 to 22KW |
Electric Power | 220V/380V/415V,50-60hz etc., |
Machine Net weight (KG) | 1600 to 16500 |
1700 to 17500 |
