Automatic double-sided feed hydraulic cutting machine is one of the typical Gerson cutting machine . The large cutting head is fixed, so large materials can be cut without difficulty.It is automatic feed the material .
Key Feature
1. The cutting head is as long as the cutting table, which makes it easy to cut large materials. The cutting die could be
combined with the beam or be placed on the material/
2. The machine equipped with sharp die is able to cut thick materials, which are soft or semi-rigid in roll or sheet.
3. Hydraulic force plays a part in most full head presses. Besides, the machines can keep balance with unique balance system when running.
4. There lots of feed modes: manual feed, auto sliding table, fully automatic cutting belt with pinch and grab pincers and powered incremental board and so on.
5. Special designed can be customized.
Model No | GRBA-100 | GRBA-120 | GRBA-150 | GRBA-200-500 |
Cutting force | 100 Tons | 120 Tons | 150 Tons | 200-500T tons |
Travel adjustment range | 0-200mm | |||
Range between the working tables | 80-280mm | |||
Size of cutting area | 1680*1120mm or 1480*1120mm | |||
Motor power | 7.5kw | 11kw | 11kw | 11kw/15Kw |
Net weight | 4500kgs | 4800kgs | 5500kgs | 7500kgs |
Gross weight | 4700kgs | 5000kgs | 5750kgs | 7800kgs |
Dimension | 2500*1800*2000mm | 2700*1800*2000mm | ||
Automatic grade | Automatic | |||
Hydraulic oil | 46# or 68# | |||
Electronic supply | 3 phase 50hz or 60hz 380V 440V or as optional | |||
Machine color | Can custom built |
