Automatic disposable face mask making machine

Automatic disposable face mask making machine is designed for making the production of flat disposable masks made of non-woven fabric.

This machine is full-automatic mask machine:

1. 1.The face making machine requires three or four rolls of non-woven fabric to be stacked and pressed together by the mask body machine (the nose tendon is synchronized and automatically cut and laminated), automatically positioned until the non-woven fabric is automatically folded, then cut and shaped and automatically discharged, the mask is transmitted by belt to the mask earbelt machine or the mask taping machine for automatic welding of the earbelt (welding earbelt with one drag one, one drag two, one drag three).
3. 2.The face making equipment will not cause adverse effects on the product, including deformation of the material, damage, appearance scratching.
5. 3.The face making equipment should be error-proof device/still, to ensure the safety of the operator and the normal use of the equipment.
7. 4.The equipment should be the whole movement process can be controlled, and have fault alarm function, disassembly and maintenance is convenient.
9. 5.Simple operation, stable operation, high loading and unloading efficiency, 2. Compact structure occupies a small area, the frame adopts aluminum alloy profile, strong and beautiful without rust.
11. 6.The disposable fully automatic mask machine mainly consists of the following mechanical components. 1). Non-woven webbing shelves. 2). The body of the mask is pressed. 3). Automatic straightening and cutting of the nasal band. 4). Automatic folding, welding and cutting.5). Conveyor belts.6). Automatic unloading of conveyor belt by ear belt welding machine, etc.
13. 7.The equipment requires low skills and proficiency of personnel; this equipment is simple to operate, the need for manual feeding only once a period of time, the whole operation process to achieve automatic operation, no manual operation, low requirements on personnel skills and proficiency.
15. 8.Equipment can save labor: the operation of equipment does not require the continuous involvement of labor, realized unmanned operation, relative to the existing state of labor savings.
17. 9.The equipment reduces the manual labor intensity; this equipment only requires manual operation for loading and unloading of material, simple and without difficulty, the last material can be buffered for a period of time, reducing the manual labor intensity, low requirements for operators.

The main technical parameters of the disposable automatic face mask machine

1.Equipment appearance size: L6500W2800H1800mm
2. Equipment should be product size: length ≤ 90mm, width ≤ 175mm, non-woven fabric not more than 3 layers
3. Equipment efficiency: 90-110 Pcs/min.
4. Plant environment: not less than 100,000 class
5. Equipment power supply voltage: AC 220V
6. Equipment access pressure: 0.4-0.7MPa.
7. Equipment power: ≈ 10KVA.
8. Gross weight of equipment: ≈ 1300 kg.
9. Number of personnel required per unit of equipment: 1 (one person can operate multiple units of such equipment).
