ARES F45 hydraulic clicking press is 20 tons pressure, cutting surface 900 x 430 mm or 900 x450mm, swing arm width 370 mm which is the same as Gerson GR-20C model. Compare to ARES F45 hydraulic clicking press ,Gerson GR-20C model is better price and high quality .Gerson also can custom build any cutting surface :900 x 450mm,1000 x 500mm ,1000 x 600mm,1200 x500mm or 600mm . and upper swing arm width 500mm or 6000mm based on your production requirement.
1.Easy to operate with swing arm and can die cut any shapes by custom die mold.
2.Two hands switches operate to ensure the operator is safe and easy.
3.The die cutitng machine is provided with automatic lubricating system to lessen abrasion and prolong service life.
4.This hydraulic clicking press is using top quality hydraulic parts and hydraulic system to make sure the machine with stable and good performance.
5.Welcome to contact Gerson for wholesales ,retails or custom built for your production.
|
Model |
GR-20C |
GR-27C |
GR-27C/1 |
GR-27C/2 |
| Max. cutting power |
20 ton |
27 ton |
27 ton |
27 ton |
| Maximum stroke(mm) |
80 |
100 |
100 |
100 |
| Cutting table(mm) |
900 x 430 |
900 x 450 |
1000 x 500/600 |
1200 x 500/600 |
| Arm width(mm) |
370 |
370 |
500/600 |
500/600 |
| Motor power |
HP. 1 |
HP. 1,5 |
HP. 1,5 |
HP. 1,5 |
| Net weight with oil |
Kg. 570 |
Kg. 780 |
Kg. 840 |
Kg. 910 |
| Sizes about (mm) |
1000 x 900 |
900 x 1000 |
1000 x 1000 |
1200 x 1030 |
| Sizes sea packing(mm) |
1050 x 1085 |
1050 x 1150 |
1150 x 1150 |
1350 x 1180 |
| Gross weight and volume with sea packing |
Kg. 640 |
Kg. 900 |
Kg. 980 |
Kg. 1055 |
