600mm and 610mm head clicker press

Gerson clicker press  have many models choice for different material die cutting .normal clicker press head or sway arm is less than 600 mm.Most of them are 370 mm,500 mm etc.,

600mm and 610mm head clicker press
600mm and 610mm head clicker press

1. The swing arm cutting machine body are welded by steel sheets with firm structure and light weight.

2. It is provided with automatic lubricating system to lessen abrasion and prolong service life.

3. Double hands operation function  guarantee the safety of operators.

4. Double-direction oil way design provides stability and reliability.

5. Two modes such as microcomputer controller and PC electronic circuit are optional for controlling the lower limit position of stroke with high precision, flexibility and convenience.

Model

GR-20C

GR-27C

GR-27C/1

GR-27C/2

Max. cutting power

20 ton

27 ton

 27 ton

27 ton

Maximum stroke(mm)

80

100

100

 100

Cutting table(mm)

 900 x 430

 900 x 450

1000 x 500

1200 x 500

Arm width(mm)

 370

370

500/600/610

500/600/610

Motor power

HP. 1

HP. 1,5

HP. 1,5

HP. 1,5

Net weight with oil

Kg. 570

Kg. 780

Kg. 840

Kg. 910

Sizes about (mm)

 1000 x 900 h. 935

900 x 1000 h. 1370

1000 x 1000 h. 1370

 1200 x 1030 h. 1370

Sizes sea packing(mm)

1050 x 1085 h. 1500

1050 x 1150 h. 1570

1150 x 1150 h. 1570

1350 x 1180 h. 1570

Gross weight and volume with sea packing

Kg. 640 m1,7

Kg. 900 m1,90

Kg. 980 m2,10

Kg. 1055 m2,50
