50 ton beam press is die cutting machine with 50T ton hydraulic pressure ,This kind of beam press is special for cutting out large width .
1.This is fixed head press that mean the upper head fixed and large area as the cutting bed .
2.This beam press using complete full oil hydraulic control system with top quality hydraulic parts. The Gerson specially designed hydraulic circuits are easy to operate and maintain.And it is working very fast and safe.
3.The machine have twin cylinder, four post column strong structure with auto-balance system ,so that make sure the machine can be delivered anywhere on the bed of the press.so can keep the machine smooth and stable.And manual four post mechanical stops for accurate bottom position control.
4.This Gerson machine designed for various workpieces in need of mold/knife/die cuttings, such as leather, plastic,eva,pe,epe, cloth, leather bags, paper,cardbord,rubber,textile,fabric,handicrafts, toys and vacuum-formed articles etc.,
5.There have many feed system to be choised depending on your production need:manual feed slide table ,Single Motorized Sliding Table,Auto double sliding table etc.,
Gerson can build any cutting solution machinery to meet your requirement.
| Model | GRB(C)-25T to 500T |
| Max cutting force(T) | From 25 Tons to 500 Tons |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting area(mm) | (500-3000)X(1000-3000)mm |
| Based on your material and die | |
| Example: 1600X600mm etc., | |
| Motor power | 1.5 to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
Gerson can make die cutting machine according to your specifical requirement :such as cutting force power,worktable size,motor,feeding type etc.,
