Gerson 30 ton clicker press have two types one is swing arm clicker press ,the other is traveling head clicker press.
Normal swing arm clicker press is from 8 tons to 28 tons.Gerson also could design and manufacture 30 ton clicker press.
Feature:
1. The machine body are cast iron with firm structure and light weight.
2. It is provided with automatic lubricating system to lessen abrasion and prolong service life.
3. Double hands operation function guarantee the safety of operators.
4. Double-direction oil way design provides stability and reliability.
| Model | Maximum Cutting power(ton) | Area of work table(mm) | Swaying arm width | Cutting table | Motor power | Machine dimensions（mm） | Net weight(with oil) | Gross weight |
| GRA-220 | 216KN(22T) | 900×430 | 370mm | 90mm | 0.75Hp | 900×850×h1400 | 650kg | 750kg |
| GRA-270/300 | 27/30 tons | 1000×500 | 370mm | 90mm | 1.1Hp | 1000×1050×h1410 | 850kg | 900kg |
