27 ton clicker press is die cutting machine manufactured by Gerson .It is the 27 ton cutting force .
1.This model have small cutitng force to 27 cutting force for small size and medium size cutting die.
2.It is hydraulic driven,Low noise and easy to operate by worker.
3.Higher speed of operation and greater productivity which can increase material yield.Compared to hand making ,it is realy good machine.
4.Application which can die cutting of materials such as leather,foam, textiles, plastic, rubber, packaging, vinyl, foam, composites, fiberglass, cork, soft wood, gasket materials (non-asbestos, teflon, etc.) and more other semi-hard material.
5.Gerson have this model from 20 ton to 27 tons. other model siwng arm clicker press from 8 ton up to 27 ton.
|
Model |
GR-20C |
GR-27C |
GR-27C/1 |
GR-27C/2 |
| Max. cutting power |
20 ton |
27 ton |
27 ton |
27 ton |
| Maximum stroke(mm) |
80 |
100 |
100 |
100 |
| Cutting table(mm) |
900 x 430 |
900 x 450 |
1000 x 500 |
1200 x 500 |
| Arm width(mm) |
370 |
370 |
500/600 |
500/600 |
| Motor power |
HP. 1 |
HP. 1,5 |
HP. 1,5 |
HP. 1,5 |
| Net weight with oil |
Kg. 570 |
Kg. 780 |
Kg. 840 |
Kg. 910 |
| Sizes about (mm) |
1000 x 900 |
900 x 1000 |
1000 x 1000 |
1200 x 1030 |
| Sizes sea packing(mm) |
1050 x 1085 |
1050 x 1150 |
1150 x 1150 |
1350 x 1180 |
| Gross weight and volume with sea packing |
Kg. 640 |
Kg. 900 |
Kg. 980 |
Kg. 1055 |
