The clicker press is from 8 tons to 28 tons cutting pressure power. According to Gerson machinery experience .25 tons clicker press can die cut most small pieces .
USE AND CHARACTERISTIC:
1. This machine are designed for cutting leather, vinyl, fabric, rubber,plastics, foam, paper, gaskets and many other soft ,non-metallic materials.
2. It is equiped with a lubricating system, to reduce wear and prolong its service life.
3.The oil way system specially designed can conveniently adjust the rocker height. No adjustment is needed after the height of die cutter is changed.
4. AN electronic time lapse system can better quality of your products and make operation simply, convenient.
5.High speed and low energy consumption.
Model:GSB-2C/25
Maximum cutting force 25 tons
Width of the swing arm 17.5″ x 19.5″
Stroke Adjustment 1/4″ – 3″
Cutting Speed 0.10m/s
Distance between arm & bench 2.5″ – 6″
Base table is 39″ wide by 19″ deep
Weight 2200 lbs dry
Motor Power 1.5 kw
Oil Tank 15 Gallon
**Note** This model also have 10 tons,12 tons,14/15/16/18 tons,20 tons.
