110 Ton Belt Die Cut Feed Press is die cutting press with belt feed system and 110 ton cutting pressure for forming most material from leather ,foam,paper,textile,plastic,fabric,cardboard etc., and for most industry: packaging, printing, carpets (floors), home textile, medical goods, PU, air conditioner seals, automobile inner decorations, adhesives and etc.,
Combine with optional feeding system to obtain automated die cutting systems for high production even with many daily die changes.
This computer-automated rule cutting machine features automated production, with highly precise electronic systems controlling the cut-lengths to.
Cutting board micro-movement device can be allocated to evenly consume the cutting board and save cost.
Hydraulic system: double oil cylinder work at the same time, and equipped with the storage energy storage device and the oil filter device.
If you have any question about the die cutting press ,please contact Gerson at any time .
| Model | GRB(C)-25T to 500T |
| Max cutting force(T) | From 25 Tons to 500 Tons |
| Range between working table | 50-240mm (Upper to Bottom Table) |
| Stroke Adjustment | 0-170mm |
| Cutting area(mm) | (500-3000)X(500-3000)mm |
| Based on your material and die | |
| Example: 1600X600mm etc., | |
| Motor power | 1.5 to 22KW |
| Electric Power | 220V/380V/415V,50-60hz etc., |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 |
