100 ton full beam hydraulic cutting machine is the hydraulic cutting machine designed by Gerson machinery.It is for cutitng large area and need enough cutting force for semi-hard material.
1.Full beam with four column and auto-balance structure.
2.Double cylinder,selfbalance connect rod which make sure high qulity.
3.100 ton cutting force ,infact st 25 Ton to the largest 500 Tons or more on request, Gerson Beam Press are adaptable to a wide range of applications.
4.Anti-shock rigid construction with mechanical balancing maintains the parallelism of the head and bed during the cutting stroke.
5.It is good for suitable for single-layer,multi-layers,r sheet or roll materials.
6. The Range of cutting force,bed size,feed type that can be customized for your application.
| Model | GRBC-25T to 500T |
| Max cutting force(T) | From 25T to 500 |
| Distance between upper press board andworktable(mm) | 50-240 |
| Cutting area(mm) | 1250×600,700,800,900,1000,1200, 1500 |
| 1470×600,700,800,900,1000,1200, 1500 | |
| 1600×600,700,800,900,1000,1200, 1500 | |
| Motor power | 1.5 to 22KW |
| Machine Net weight (KG) | 1600 to 16500 |
| 1700 to 17500 | |
| 1800 to 18500 |
